Nasir Nickel Alloys, a leading manufacturer and supplier based in Manama, Bahrain, proudly offers Titanium Grade 5 Bars renowned for their exceptional strength and versatility. Ideal for aerospace, automotive, and industrial applications, these bars are crafted from titanium alloy that combines titanium with aluminum and vanadium for superior mechanical properties. Our Titanium Gr 5 Bars are characterized by excellent corrosion resistance and high strength-to-weight ratio, ensuring durability and reliability in demanding environments.
Titanium Gr 5 bars are made from 6% aluminum, 4% vanadium, and titanium with few other elements. They exhibit high tensile strength (up to 1,200 MPa), good corrosion resistance and good fatigue strength. The alloy retains its strength at high temperatures, making it ideal for aerospace and industrial applications. Its low-density results in a lightweight yet durable material, which helps it perform well in harsh environments. This combination of characteristics makes Titanium Gr 5 Bars desirable for high-performance applications.
| Specifications Chart | ASTM B348/ ASTM SB348 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size in mm | 5 mm To 500 mm |
| Diameter in mm | 0.1 mm to 100 mm |
| Length in mm | 100 mm To 3000 mm Long & Above |
| Surface Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Grade | Ti | C | Fe | Al | V | O |
|---|---|---|---|---|---|---|
| Titanium Grade 5 | 90 min | – | 0.25 max | 6 min | 4 min | 0.02 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Gr 5 Bars in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Gr 5 alloys are widely used in the aerospace, automotive and marine industries due to their high strength and weight and excellent corrosion resistance Typical applications are aircraft structural components, engine components and seafood products. It is used in medical implants and high-performance sports equipment. Alloy’s ability to withstand extreme temperatures and harsh environmental conditions makes it ideal for complex applications where durability and reliability are important and its versatility and performance make it a popular choice for both technical and special applications.
