Nasir Nickel Alloys in Manama, Bahrain, manufactures and supplies high-quality Phosphorous Bronze sheets and plates known for their excellent combination of strength, hardness, corrosion resistance, and wear resistance. These copper-tin alloys, typically designated as CW451K or UNS C51000, contain phosphorus which enhances their mechanical properties and fatigue strength. Nasir Nickel Alloys ensures precise production to meet industrial requirements, making their phosphorous bronze sheets and plates suitable for diverse engineering applications.
Phosphorous Bronze sheets and plates generally consist of about 88-96% copper, 4-5.5% tin, and 0.01-0.4% phosphorus, with minor amounts of lead, zinc, nickel, and iron depending on the grade. They have a melting point around 930°C and density approximately 8.85 g/cm³. Mechanical properties include tensile strength from 320 to 740 MPa, hardness between 75 to 230 HV, elongation from 2 to 45%, and a modulus of elasticity around 121 GPa. These materials also exhibit good machinability, fatigue resistance, and low magnetic permeability.
| Material | Phosphor Bronze Sheet/Plate |
| Grade | Alloy 510, Alloy 521, Alloy 519, Alloy 544 |
| Standard | ASTM B103 |
| Size | Thickness 0.1 mm to 50 mm; Width up to 500 mm; Length up to 2000 mm |
| Surface | Rolling surface, Chemical cleaned, Grinding |
| Element | Zinc (Zn) | Iron (Fe) | Tin (Sn) | Copper (Cu) | Lead (Pb) | Phosphorous (P) | Nickel (Ni) | Others |
|---|---|---|---|---|---|---|---|---|
| % | .00 – .20 | .00 – .10 | 4.50 – 5.50 | Balance | .00 – .02 | .01 – .40 | .00 – .20 | .00 – .20 |
| Tensile strength | Hardness | Elongation at break | Modulus of elasticity | Izod impact strength | Shear strength |
|---|---|---|---|---|---|
| 320 – 740 MPa | Brinell : 80 – 225 | < 60 % | 90 – 120 GPa | 62 J m⁻¹ | 250 – 430 MPa |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Phosphorous Bronze Sheets and Plates in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Phosphorous Bronze sheets and plates are widely used in electrical connectors, marine and chemical hardware, power generation, automotive components, shafts, gears, and decorative applications. Their excellent corrosion resistance, fatigue strength, and wear resistance make them ideal for manufacturing springs, bearings, bushings, and precision components exposed to mechanical stress and harsh environments. The alloy’s versatility supports long-lasting usability in critical industrial and commercial uses.
