Home > Manganese Bronze Sheets and Plates
Manganese Bronze Sheets and Plates are high-strength copper-based alloys known for their excellent durability, toughness, and corrosion resistance. Composed primarily of copper, zinc, manganese, iron, and trace elements, these alloys offer outstanding mechanical properties and long service life in demanding environments. Manganese Bronze is valued for its superior wear resistance, exceptional load-bearing capacity, and ability to withstand shock and high-stress conditions. These sheets and plates are widely used in marine hardware, heavy-duty industrial components, and applications requiring strong, corrosion-resistant materials capable of performing reliably in seawater and harsh operating conditions.
Manganese Bronze Sheets and Plates contain a balanced mix of copper and zinc, enhanced with manganese, iron, and aluminum for increased strength and durability. This alloy demonstrates excellent tensile and yield strength, elevated hardness, and superior fatigue resistance. Manganese Bronze provides exceptional corrosion resistance, especially in seawater and industrial atmospheres, making it ideal for marine and offshore applications. Its high mechanical stability and low friction characteristics allow it to carry heavy loads and resist deformation, ensuring reliable performance in high-impact or high-stress environments.
| Standard | JIS H3250-2006,ASTM B152M,GB/T2040-2008,ASTM B36,ASTM B194,ASTM B888, ASTM B19,ASTM B122,etc |
| Thickness | 0.1-120mm |
| Width | 2-2500mm |
| Length | 1m,2m,3m,6m,or as required |
| Surface | mill,polished,bright,mirror,hair line,brush,checkered,antique,sand blast,etc |
| Container size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
| Application | Brass plate has a high corrosion resistance, and have good plasticity,in the air easy to cold and hot pressure processing,easy to welding, forging and tin, no stress corrosion cracking the tendency. |
| Cu(1) | Al | Fe | Pb | Mn | Sn | Zn | |
| Min./Max. | 57.0-60.0 | .25 | .8-2.0 | .20 | .05-.50 | .50-1.5 | Rem. |
| Nominal | 58.5 | – | 1.4 | – | .10 | 1.0 | 39.0 |
| ensile Strength, min | Yield Strength, at 0.5% extension under load, typ | Elongation, in 2 in. or 50 mm typ | Brinell Hardness (500 kg load) | Remarks | ||
|---|---|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % | typical BHN | |
| 65 | 448 | 25 | 172 | 20 | 90 | |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Manganese Bronze Sheets and Plates in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Manganese Bronze Sheets and Plates are widely used across industries where high strength and resistance to corrosion and wear are essential. In the marine sector, they are used for propeller components, shafts, bearings, and underwater hardware. Industrial applications include pump parts, valve components, hydraulic fittings, gears, and heavy-duty bushings. The alloy’s strong load-bearing properties make it suitable for construction machinery, locomotive components, and mining equipment. Manganese Bronze Sheets and Plates are also used in electrical systems, architectural structures, and precision engineering components where durability and long-term stability are critical.
