At Nasir Nickel Alloys in Manama, Bahrain, Incoloy Forged Fittings are developed to perform reliably in environments where heat, corrosion, and mechanical stress are constant factors. Manufactured from high-strength nickel-iron-chromium alloys, these fittings are engineered to deliver stable, long-term performance across a wide range of demanding industrial conditions. Each fitting is crafted with precision to ensure secure, leak-proof connections and dependable operation under fluctuating temperatures and pressures. With a strong focus on real-world requirements, these forged fittings provide durable, corrosion-resistant solutions for industries that depend on consistent, high-quality components.
Incoloy Forged Fittings are produced from nickel-iron-chromium alloys containing additions such as molybdenum, titanium, and copper, depending on the specific grade. This balanced composition provides excellent resistance to high-temperature oxidation, carburization, and corrosive chemicals. Mechanically, Incoloy alloys offer high tensile and yield strength, strong creep resistance, and excellent toughness across elevated and fluctuating temperature ranges. These fittings maintain structural integrity under heavy loads, thermal cycling, and pressure variations, ensuring long-term reliability in harsh operating conditions.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Incoloy 800, 800H, 800HT, 825, 925 Forged Fittings
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Forged Fittings | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Forged Fittings | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Forged Fittings in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Incoloy Forged Fittings are widely used in industries that require exceptional durability in high-temperature and corrosive environments. They are commonly utilized in chemical and petrochemical processing, power generation units, heat exchangers, furnace equipment, and gas turbine systems. Their stability makes them suitable for sour gas environments, refinery systems, and high-pressure piping networks. In marine and offshore applications, they perform reliably in chloride-rich and corrosive atmospheres. With strong resistance to thermal and chemical degradation, these fittings support safe, efficient, and long-lasting operation across a broad spectrum of critical industrial processes.
