Hastelloy Ball Valves are designed to withstand the toughest industrial conditions, offering remarkable corrosion resistance, reliability, and durability. Made from high-quality Hastelloy grades like C276 and C22, these valves excel in resisting strong acids, chlorides, oxidizing agents, and high-temperature corrosion. Their sturdy build ensures smooth flow control, leak-proof sealing, and a long lifespan, even when faced with extreme pressures and temperatures. You’ll find these valves commonly used in chemical processing, petrochemicals, pharmaceuticals, offshore applications, and pollution control systems. Built for demanding tasks, Hastelloy Ball Valves promise consistent performance, impressive mechanical strength, and reliable control in corrosive and high-stress environments.
Hastelloy Ball Valves are made from a blend of nickel, molybdenum, and chromium, with added tungsten and iron to boost their corrosion resistance and mechanical stability. This unique composition allows them to thrive in both reducing and oxidizing environments. On the mechanical side, Hastelloy boasts high tensile strength, exceptional toughness, and impressive creep resistance at elevated temperatures. The alloy remains structurally sound under intense stress and shows remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking. Plus, these valves are known for their excellent weldability and durability, making them perfect for critical flow-control tasks in aggressive industrial settings.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Ball Valve in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Ball Valves are a go-to choice in industries that need top-notch flow control, especially in harsh and corrosive environments. You’ll often find them in chemical processing plants, where they can handle tough acids like sulfuric, hydrochloric, and nitric acid without breaking a sweat. In the pharmaceutical and food sectors, they ensure a contamination-free operation, which is crucial. These valves are also essential in petrochemical refineries, offshore and marine systems, desalination plants, pulp and paper processing, and pollution control equipment. Thanks to their impressive strength and resistance to corrosion, they excel in high-pressure lines, gas handling systems, reactors, heat exchangers, and high-temperature fluid control tasks, guaranteeing reliability and a long service life.
