Home > Nickel Alloys > AWS Class ERNiCrMo-13 MIG and TIG Filler Welding Wire and Rod
The AWS Class ERNiCrMo-13 MIG and TIG Filler Welding Wire and Rod are top-notch nickel-chromium-molybdenum alloy fillers crafted for outstanding corrosion resistance and top-notch weld integrity. These fillers are a go-to choice for joining high-alloy materials that face tough chemical environments, whether they’re dealing with oxidizing or reducing media. ERNiCrMo-13 shines with its excellent weldability, impressive mechanical strength, and strong resistance to pitting and crevice corrosion. It’s perfect for welding nickel-based alloys found in chemical processing, pollution control, aerospace, and marine settings. With its stable arc performance, beautiful bead appearance, and ability to handle extreme temperatures, it’s a reliable option for critical industrial welding tasks.
Typically, the AWS ERNiCrMo-13 Filler Wire and Rod are made with nickel as the primary element, blended with chromium, molybdenum, tungsten, cobalt, iron, and some trace elements to boost performance. This well-balanced mix offers remarkable corrosion resistance against chlorides, acids, and high-temperature conditions. On the mechanical side, the filler boasts high tensile strength, excellent creep resistance, and impressive toughness, even in extreme situations. It maintains strong metallurgical stability, ensures crack-free welds, and can handle thermal cycling. These qualities make ERNiCrMo-13 ideal for welding demanding alloys in harsh chemical, petrochemical, and high-temperature environments.
| Classification | AWS A5.14, ERNiCrMo-13 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCrMo-13 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Co | Cr | Mo | V | W | Other |
| 0.02 | 1.0 | 4.0-7.0 | 0.04 | 0.03 | 0.08 | 0.50 | Rem | 2.5 | 14.5-16.5 | 15.0-17.0 | 0.35 | 3.0-4.5 | 0.5 |
| Tensile Strength MPa(ksi) | Yield Strength MPa(ksi) | Elongation % | |
|---|---|---|---|
| AWS requirement | 760(110) | Not specified | Not specified |
| Typical results as welded | 700(102) | 400(58) | 30 |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiCrMo-13 MIG and TIG Filler Welding Wire and Rod in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS ERNiCrMo-13 MIG and TIG Filler Welding Wire and Rod are popular choices in industries that need strong, corrosion-resistant welds. They’re perfect for joining nickel-chromium-molybdenum alloys, which are commonly found in chemical reactors, heat exchangers, distillation equipment, offshore platforms, and marine parts. These fillers excel in tough environments, including those with chlorides, sulfuric acids, seawater, and extreme temperatures. You’ll also find them in flue-gas desulfurization systems, power generation plants, aerospace components, and pressure vessels. ERNiCrMo-13 guarantees high-quality welds with outstanding stability, making it a go-to for critical fabrication where both structural integrity and corrosion resistance are a must.
