Alloy C263 Foil is a robust nickel-cobalt-chromium-molybdenum alloy that stands out for its high strength and resistance to corrosion. It’s specifically crafted for situations where excellent thermal stability and top-notch mechanical performance are a must. This alloy is well-regarded for its remarkable ability to resist oxidation and stress corrosion cracking, making it a go-to choice in high-temperature settings where durability and reliability are crucial. Thanks to its impressive formability and weldability, Alloy C263 foil is perfect for creating precision components in industries like aerospace, power generation, and chemical processing. It retains its strength even at elevated temperatures, ensuring consistent performance, structural integrity, and outstanding resistance to creep, which is why it’s favored in demanding operational environments.
Alloy C263 Foil is mainly made up of nickel, with notable amounts of cobalt, chromium, molybdenum, titanium, and aluminum. This well-balanced chemical makeup gives it excellent oxidation resistance and remarkable strength at high temperatures. On the mechanical side, Alloy C263 boasts high tensile strength, impressive creep resistance, and superior fatigue performance. It also maintains good ductility and stability during thermal cycling. The alloy’s unique metallurgical structure boosts its resistance to stress corrosion cracking, ensuring reliable performance in high-temperature, high-stress applications that demand precision and long-lasting durability.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
At Nasir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Alloy C263 Foil in Manama, Bahrain, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Bahrain, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Alloy C263 Foil is a go-to material in industries that need exceptional strength at high temperatures, along with great corrosion resistance and thermal stability. You’ll often find it in aerospace engines, gas turbines, combustor liners, transition ducts, and heat shields, thanks to its impressive ability to resist creep and oxidation. In the realm of chemical processing, it plays a vital role in reactors, heat exchanger components, and systems that handle high-temperature chemicals. Power generation plants also rely on this foil for turbine components, combustion systems, and parts that endure high stress. Plus, its remarkable formability and durability make it perfect for precision-formed parts, aerospace insulation, and high-performance industrial equipment.
